314S-SS • 12 Blades
314S-SS
• Tip speed up to 100 m/s
• Output 9 – 90 Kg/hr.
• Variable speed.
• Removable chamber door to allow for screen change.
• Reversible rotor allowing for change between blade faces.
• Ideal for Research and Development and test processing.
• Easy access components.
• Safety interlocks. -
SSU2-114 • Continuous production.
SSU2-114
• Controls remotely mounted.
• Feed to the Mill is from an IBC from the floor above and product discharge into a further IBC on the floor below
• A Rotary Valve Feeder controls the feed rate and the entire system is inerted against dust explosion by gaseous Nitrogen.
• Additional features include a pulsed automatic filter cleaning system, Wash-In- Place facilities and a safe change HEPA filter.
• Ideal for Pharmaceuticals, Waxes, Herbs and Sugars.
-
SSU2-114 • 16 Blades.
SSU2-114
• Tip speed up to 133 m/s.
• Output 225 – 700 Kg/hr.
• Variable speed.
• Easy access components.
• Safety interlocks.
• Many configuration options
• Ideal for Pharmaceuticals, Waxes, Herbs and Sugars.
-
180 Model 180 Model
180 Model
• 430 – 1360 kg/hr.
• 16 Blades
• Tip speed up to 100 m/s
• 37.5 Kw motor
• Ideal for products requiring large size reduction e.g. cooked meat and vegetables to puree.
COMMINUTING MILLS
Through continual development over the years, Apex are now proud to offer a range of 4 types of comminuting mills, SSU2-314, SSU2-114, 314S-SS and 180 models.
All of which can be configured to accommodate a vast number of applications, installations, operation environments, and ATEX compliance.
Chamber designs are all stainless steel, smooth walled, crevice free, fully welded construction, which enables easy manual cleaning, or washed in place by the use of hot water or super-heated steam – if specified.
The SSU-114 and 180 models are available in double width for increased throughput for extremely high demand production volumes.
Here are our standard screens, however we are able design and produce any aperture that you require, please contact us with your requirements.
Download Screen Data File
A feature, which greatly extends the flexibility and versatility of the Apex Mill, is the Comminuting Mill Chamber with revisable rotor and blades. It is specifically designed for dual faced blades. Several blade/hammer types have been developed – each having specially designed for certain operations and products.
Download Blade Type Data File
Typical Apex Mill performance data for various products.
